The Manta7 X Lite is a fixed-frame, seven-inch FPV model. The True X layout puts the four arms around a central body, with the camera at the front and the battery carried above the plates. It is a different physical proposition from the folding KOLAS7, even though both use the same broad propeller-size category.
Axisflying lists this model with analogue 5.8 GHz video and a 3 W transmitter description. That identifies the advertised video version, not a distance guarantee or an instruction to use a particular power setting. The fitted transmitter model and permitted regional configuration should be specified with the aircraft.
Use the underside to identify the structure
The underside reference shows the long arms and central plate arrangement clearly. When buying replacement carbon, compare the exact Manta7 X Lite part and revision. A generic seven-inch arm may differ in thickness, attachment position or wiring clearance even when the motor-end holes look similar.
The earlier frame specification lists a 340 mm wheelbase and a 30.5 mm stack pattern. Treat these as mechanical references, not a complete electronics list. The flight controller, ESC and motor models still need to be recorded for the assembled aircraft.
Radio and viewing equipment
The manufacturer offers ELRS 2.4G and TBS receiver choices for this model. Choose the appropriate control package independently of the analogue video system. Confirm your goggles can receive the supplied video format and that their antenna arrangement is appropriate for the equipment.
The photographs show the external arrangement, but cannot identify every board or receiver revision. Request a concise installed-parts list instead of assuming the visible antennas establish the complete system.
Complete weight and maintenance
Select a battery only after checking the specified electrical components and physical battery space. Include the pack and any filming accessory when comparing takeoff weight. A propeller-size label alone cannot predict flight duration, carrying capacity or a suitable operating distance.
Inspect the arm attachments, landing pieces, battery retention and exposed leads after transport or a hard landing. Obtain matching propellers and frame spares with the aircraft. Compare the Axisflying model range if folding storage or a smaller airframe is more useful for the intended recreational flying.
Manta7 X Lite reference
Structure
True X; seven-inch aircraft family
Frame reference
340 mm wheelbase; 30.5 mm stack pattern
Video listing
Analogue 5.8 GHz, advertised 3 W variant; confirm installed model
Receiver options
ELRS 2.4G or TBS
Power system
Obtain the assembled motor / ESC / battery specification
