Sector X5 HD: choose the video build before the accessories

The HGLRC Sector X5 is a five-inch freestyle and racing platform with replaceable arms, a fixed power connection and a frame layout intended for an HD camera system. The product description identifies the Sector X5 FR frame, CNC aluminium side plates and printed mounting parts.

“HD Version” identifies a product family here, not one uniquely specified air unit. Vista HD and DJI O3 HD appear as alternative configurations. The ZEUS analog transmitter mentioned elsewhere in the component list is not the HD package described by this title.

Two HD options to distinguish

VISTA HD

Confirm the fitted kit

The source names Vista without a complete camera or receiver specification. Ask which camera, antennas and receiver are installed, then match them to your viewing and control equipment.

DJI O3 HD

Confirm the O3 build

O3 is a separately named choice. Its inclusion should be explicit on the order; it cannot be inferred merely from an HD product photograph or the frame name.

Three useful details in the frame layout

Replaceable arms: The arm design is intended to allow replacement without dismantling the whole frame. Confirm the matching arm revision when ordering a spare; the description gives no guaranteed repair time.
Fixed power connector: The power port has a defined mounting position rather than relying on a freely moving lead. Cable condition and clearance still need inspection on the assembled aircraft.
Camera support: The lens mount and frame parts are designed around the video installation. Claims of reduced vibration do not replace a recording from the actual camera and propeller combination.

Receiver, battery and package scope

The listed package contains the aircraft, a Hammer Mini SMA antenna, two 20 × 250mm straps and eight S5 propellers. The receiver is explicitly optional. Confirm the final accessory list for the chosen HD kit; an antenna in a general package list does not prove compatibility with every video variant.

A 6S 1300–2200mAh LiPo is the published battery recommendation. It is not a supplied-battery promise or an endurance figure. The specified M80 GPS likewise does not establish a successful Rescue configuration or guaranteed return; check the installed firmware and configuration record.

If comparing another HGLRC frame, use the HGLRC product range, while keeping this aircraft's exact HD and receiver choices on the quotation.

Airframe

Sector X5 FR; 215mm wheelbase; listed dimensions 230 × 184mm

Motor reference

SPECTER 2306.5 1900KV, listed for the 6S build

ESC reference

SPECTER 60A 4-in-1; source lists 60A continuous / 65A burst and BL32 firmware

Navigation hardware

M80 GPS module

Propeller reference

HQProp / Ethix S5, five-inch tri-blade

Controller identification

F722 MINI, STM32F722 and MPU6000 are named in the specification, but the feature text calls the system F760. Verify the board label before selecting firmware or replacement electronics.
