SIYI MK32 7-Inch Drone Controller with Ethernet and HDMI

Price	On request
Model	MK32
Display	7-inch LCD touchscreen
Operating system	Android 9.0
Handheld battery	10,200 mAh, 7.4 V, 2S Li-ion; 75.48 Wh
Memory	4 GB RAM
Storage	64 GB storage
Charging	PD 30 W
Control channels	16 physical channels; 16 communication channels
Ground-unit weight	1,440 g including battery and antennas
Ground interfaces	USB-A, Type-C, Ethernet LAN, SIM and TF card slots; bottom RC signal port

Get Quote

+86-13959965075

SIYI MK32 · ANDROID GROUND CONTROLLER

Start with the camera connection, then select the MK32 package

The SIYI MK32 combines a 7-inch touchscreen, Android 9, physical aircraft controls and a digital link in a handheld drone controller. It suits a project that needs flight information and a live camera picture in one terminal. The important purchase choice is the video source: an Ethernet camera and an HDMI camera require different aircraft-side arrangements, even though the operator may use the same MK32 ground unit.

SIYI MK32 handheld ground station with screen and physical flight controls — MK32 ground terminal from the manufacturer package list.

Ethernet camera route

Use the air unit's network-video input as the starting point for a supported Ethernet camera. Compare the camera stream and ground application with the intended MK32 configuration. This route keeps the camera-to-link connection separate from the HDMI output on the handheld terminal.

HDMI camera route

SIYI describes an optional aircraft-side HDMI input converter supplied with the HDMI combo. It accepts Micro-HDMI and outputs Ethernet. Include that converter when required; the presence of HDMI on the ground controller does not turn its air unit into an HDMI camera input.

A 7-inch Android workspace with physical controls

The ground unit has 4 GB RAM and 64 GB storage. Its 16 physical and 16 communication channels give an integrator a defined starting point for aircraft and payload functions. A working assignment still depends on the selected vehicle, application and configured functions; the number is not a promise that every optional payload can be operated without integration.

For field use, the published battery is a 10,200 mAh, 7.4 V, 75.48 Wh pack with PD 30 W charging. SIYI lists 10 hours of battery life and 3.5 hours charging with the specified charger. Compare those manufacturer figures with the brightness, peripherals and workload expected during your own work period. The 1,440 g ground-unit weight includes the battery and antennas.

MK32 air-unit component with cooling fan and antenna leads — Aircraft-side component pictured for the MK32 package; order contents depend on the selected combo.

Core specifications for the MK32 configuration

Display	7-inch LCD touchscreen
Operating system	Android 9.0
Memory	4 GB RAM; 64 GB storage
Channel count	16 physical; 16 communication channels
Ground video output	Standard HDMI
Ground connections	USB-A, Type-C, LAN, SIM and TF card slots; bottom RC signal port
Battery	10,200 mAh, 7.4 V; 75.48 Wh
Charging	PD 30 W; 3.5 hours listed
Ground-unit size	308 × 148 × 72 mm with antennas overlapped
Ground-unit weight	1,440 g including battery and antennas

Three choices that shape the finished kit

Name the camera output. An existing Ethernet camera, an HDMI camera and an optional recording FPV camera lead to different combinations. Specify the actual model rather than asking only for a controller with video.
Name the flight-control connection. The documented air unit provides S.Bus, PWM and UART-related interfaces for their respective control and data tasks. The controller family and firmware should be part of the integration discussion.
Choose the operator's viewing arrangement. The built-in screen is the primary handheld workspace; ground-terminal HDMI can serve an external viewing screen. Decide which arrangement the quotation should include.

The manufacturer lists a 15 km maximum transmission figure under unobstructed, interference-free conditions. It is a conditional system reference, not a promised working radius for a particular aircraft or location. Our quotation should identify the air unit, antenna set and video package instead of applying an expanded-range headline to every MK32 kit.

MK32 buying questions

Is this the MK32E?

This page covers the MK32. SIYI publishes a separate MK32E manual, so the model suffix and actual package should be confirmed before comparing specifications or ordering replacement parts.

Does the standard controller include an HDMI camera converter?

The converter is an optional component associated with the HDMI combo. Ask for it explicitly when your aircraft camera supplies HDMI video.

Can I compare it with a smaller SIYI controller?

Yes. The MK15 Enterprise ground station is another existing option. Begin the comparison with screen size, application requirements and the camera package you intend to operate.

Request the right MK32 combination

Share your aircraft controller, camera model, camera output type, ground application and any need for an external monitor. FD can then quote the MK32 ground unit, matching air unit and relevant video accessories as a defined package, making the comparison with an existing setup much easier.

SIYI MK32 specifications

Display	7-inch LCD touchscreen
Operating System	Android 9.0
Memory	4 GB RAM; 64 GB storage
Channels	16 physical channels; 16 communication channels
Ground Video Output	Standard HDMI
Ground Connections	USB-A, Type-C, Ethernet LAN, SIM and TF card slots; bottom RC signal port
Ground Battery	10,200 mAh, 7.4 V, 2S Li-ion; 75.48 Wh
Charging	PD 30 W
Listed Ground Endurance	10 hours; manufacturer figure
Ground Weight	1,440 g including battery and antennas
Ground Dimensions	308 × 148 × 72 mm with antennas overlapped
