| Price | On request |
|---|---|
| Model | A8 mini |
| Visible camera | 8 MP 1/1.7-inch sensor; fixed lens; 21 mm equivalent focal length |
| Stabilization | Three-axis yaw, pitch and roll |
| Video output | Ethernet / CVBS / micro-HDMI |
| Storage | MicroSD Class 10 up to 256 GB; JPG / MP4; FAT32 or exFAT |
| Dimensions | 55 × 55 × 70 mm |
| Weight | 95 g |
| Lens configuration | 21 mm equivalent; fixed optics |
| Control interfaces | S.Bus / UART / Ethernet UDP or TCP |
A8 mini is a 95 g, three-axis visible-light camera for small UAV imaging projects. Its fixed lens keeps the camera compact, while recording modes give you a choice between a detailed wide view and digital enlargement. For FPV UAV builders adding a separate inspection camera, start with the footage you want to save and the video connection your aircraft already uses.
The headline 6× zoom belongs to the 720p mode. A8 mini does not combine 4K recording with 6× zoom, and it does not contain an optical-zoom lens. Select a mode according to the task rather than treating every setting as available at once.
| Recording mode | Digital zoom available | Selection angle |
|---|---|---|
| 4K at 25 fps | No zoom | Keep the wide scene and more recorded detail |
| 2K | Up to 3.5× | Balance image size with enlargement |
| 1080p | Up to 5.5× | Use an HD recording workflow |
| 720p | Up to 6× | Choose the largest digital enlargement |
The camera has an 8 MP, 1/1.7-inch sensor and a fixed lens with a 21 mm equivalent focal length. It suits general site documentation, daylight roof inspection and operator-controlled viewing where thermal imaging is not part of the job.
The listed camera dimensions are 55 × 55 × 70 mm. Plan space for gimbal movement, the mount and cables as well as the camera body. Use 95 g as the camera mass, then add the mounting and wiring items chosen for your aircraft.
Ethernet, CVBS and micro-HDMI provide video connection choices. S.Bus, UART and Ethernet UDP/TCP provide control choices. Local recording uses a microSD card up to 256 GB, with MP4 video and JPG photographs. A camera recording in 4K still needs a compatible video link and ground display for live viewing; choose that path independently.
No. The 4K mode has no zoom. The maximum 6× digital zoom is available in 720p mode.
No. It is a single visible-light camera. Choose a dual-sensor gimbal when heat patterns are part of your inspection.
The manual states that saved-photo resolution follows the selected video mode. Set the recording mode before planning your image deliverable.
AI tracking uses an optional module. Request the module and its connection items if that function is needed.
Share the aircraft, payload limit, mount, power supply, preferred recording mode and video receiver. Include the control connection and any tracking-module requirement. FD will use those details to quote a camera kit that matches your installation.
Technical reference: SIYI A8 mini specifications and SIYI A8 mini User Manual v1.10.
| Stabilization | Three-axis yaw, pitch and roll |
|---|---|
| Visible Camera | 8 MP 1/1.7-inch sensor; fixed lens; 21 mm equivalent focal length |
| Video Recording | 4K at 25 fps with no zoom; 2K, 1080p and 720p also listed |
| Digital Zoom By Mode | 4K none; 2K up to 3.5×; 1080p up to 5.5×; 720p up to 6× |
| Still Photography | Saved-photo resolution follows the selected video recording mode |
| Weight | 95 g |
| Dimensions | 55 × 55 × 70 mm |
| Video Output | Ethernet / CVBS / micro-HDMI |
| Control | S.Bus / UART / Ethernet UDP or TCP |
| Storage | MicroSD Class 10 up to 256 GB; JPG / MP4; FAT32 or exFAT |
Select SIYI A8 mini 4K drone gimbal camera for compact UAV imaging. Compare recording modes, digital zoom, 95 g camera mass and video connection choices....
Choose SIYI ZT6 dual sensor gimbal camera for UAV inspection: 640 thermal imaging, fixed lenses, three-axis control and a matched video and mounting kit....
