G982-4G RTK Module Real Time 4G Link FPV Drone Kit

Price: $
Model: G982-4G positioning evidence

Get Quote


G982-4G evidence chain

Approve the positioning chain, not a centimetre headline

G982-4G positioning claims require observable chain evidence. Receiver and modem revisions, antennas, correction transport, timing logs, coordinate handling and a lawful checkpoint sample belong to one acceptance file. The G982-4G archive lists a UM982 receiver, EC600M cellular module, ESP32S3 processor, QMC5883L magnetometer, 1408 channels, multi-constellation signals, UAVCAN, 20Hz positioning and raw observations, plus RTCM 3.x. It states 5V at 1.2A, 65 × 45 × 14mm, 55 × 55mm mounting and 22.5g. Published RTK and timing figures remain conditional until antennas, corrections, baseline, firmware and test method are attached to the delivered module.

QuickRTK 4G enclosure with two long cabled antennas and one short side antenna fitted.
This assembled view records the three visible antenna paths and enclosure form; it cannot prove correction service, network bands or positioning accuracy.
Three-quarter QuickRTK 4G view showing two top coax connectors, long antennas, a side whip and enclosure ports.
The closer angle helps identify connector placement and cable routing; current manuals still govern antenna purpose, cellular region and power.

G982-4G acceptance bundle

  1. Record receiver, modem and processor revisions.
  2. Name both antennas, cables and mounting separation.
  3. Document correction source and cellular responsibility.
  4. Capture fix status, RTCM and synchronized raw logs.
  5. Compare a lawful known-point sample before release.

G982-4G positioning chain

Evidence linkArchive statementAcceptance record
ReceiverUM982 and listed satellite signalsHardware revision, enabled bands and firmware
CorrectionsEC600M 4G and RTCM 3.xCarrier, service, protocol, credentials handling and correction log
Orientation/time0.1 degrees at 1m; PPS 20nsAntenna baseline, cable delay and synchronized observation
Power/mechanics5V 1.2A; 65 × 45 × 14mm; 22.5gConnector, mounting drawing and measured installed load

The cellular link is only one part of RTK

Specify SIM and carrier responsibility, supported network bands, correction transport, reconnect behaviour and data ownership. Loss of cellular service should be visible in logs; it must not be hidden behind a generic real-time monitoring claim.

Validate output against the intended civil task

For mapping or inspection, save raw and corrected outputs, fix status, antenna geometry, firmware, coordinate frame, timestamps and a checkpoint comparison. A receiver data-sheet value is not the same as project accuracy after mounting and processing.

G982-4G procurement questions

Does the EC600M modem include a correction subscription?
The archive does not establish that; define SIM, carrier, correction account and renewal ownership.
Is the listed RTK accuracy guaranteed after installation?
No. Antennas, corrections, environment, coordinate handling and validation determine the result.
What should be saved from acceptance?
Retain firmware, configuration, raw observations, correction status, timestamps and checkpoint comparison.
Define a G982-4G verification dataset

Share correction service, antenna layout and output format so the evidence chain can be scoped.

Review FPV component and kit listings
Field Evidence

G982-4G evidence card

Positioning acceptance joins hardware identity to corrections, timing and project validation.

01
Record receiver, modem and processor revisions with both antenna paths.
02
Document correction source, cellular responsibility and reconnect visibility.
03
Preserve raw observations, synchronized status and a known-point comparison.
