RW10 Industrial Terminal with Dual OS and 20KM Wireless Drone Kit

Price: $
Model:

Get Quote


  1. Product Overview
    RW10 is a high-performance smart terminal device designed for industrial automation, remote monitoring, and field operations. It supports both Windows and Ubuntu 20 OS, and features a 10-inch HD high-brightness display, a 5.8GHz long-range wireless module, and a high-capacity battery to handle complex usage scenarios.
  2. Key Features
    Dual-System Support
    Compatible with Windows and Ubuntu 20, meeting various application needs.
  3. Sunlight-Readable Display
    10-inch high-brightness screen ideal for outdoor use.
  4. 20KM Long-Range Wireless
    Equipped with 5.8GHz communication module for extended video transmission.
  5. Long Battery Life
    Powered by a 4400mAh battery for continuous operation in the field.
    hardware configuration Product Name WinPad
    Dimensions 357L190W40mmH
    Weight 1.5kg
    Configuration High-resolution, high-brightness 16+256G
    Screen Size 10.1 inches, 16:10
    Screen Resolution IPS 1920*1200
    Screen Brightness 700cd/m²
    TP Touch Screen 10-point touch G+G, hardness ≥7H, supports medical rubber glove touch
    Battery 7.6V 5550mAh high-voltage lithium battery, non-removable, battery life ≥7h (1080P+50% brightness)
    Speaker, Microphone *2, Speaker 1.2W/8Ω 1, MIC
    CPU Intel JASPER LAKE N5100 processor, 4 cores 4 threads, 1.1GHz-2.8GHz
    RAM/ROM 8G+128GB /16G+256GB
    TPM Built-in TPM security chip
    Gravity Sensor OK
    system Operating System Windows 10
    Wireless connection function WIFI WIFI 802.11(a/b/g/n/ac), 2.4G+5.8G dual-band WIFI
    Bluetooth Bluetooth 4.0 (BLE) class1, transmission distance: 10m
    GPS GPS, GLONASS (U-BloxM7N)
    Network interface TYPE-C *1, Type-C
    Type-A *1, USB3.0
    TF Card *1, supports up to 1TB expansion
    SIM Card *1, standard Micro SIM card slot
    HDMI *1, Micro HDMI
    DC Interface *1, 12V-4A (DC plug outer diameter 3.5mm, inner diameter 1.35mm)
    Ethernet Port *1
    product reliability Operating Temperature -20℃~60℃
    Storage Temperature -30℃~70℃
    Humidity Humidity: 95% Non-Condensing
    Certifications IP68, 3C, CE, MIL-STD-810G certification, energy-saving certification, ISO quality management system, ROHS, three-proof salt spray test
    Adapter 12V-4A, DC power adapter -20℃~60℃
    Image transmission data RF Band 1427.9-1447.9MHz
    Power Level 1.4G 25dBm+2
    Transmission Mode Unicast, Multicast, Broadcast
    Power Control Adaptive control for slave nodes, fixed power for central node
    Configuration Management WEBUI
    Anti-Interference Supports frequency hopping
    Transmission Mode Single antenna transmission, dual antenna reception
    Central node uplink/downlink time slot ratio support
    Master-Slave Data Bidirectional Communication
     2D3U/3D2U/4D1U/1D4U
    Encryption ZUC, SNOW3G, AES (optional)
    Network Node Count Up to 16 access nodes
    Transmission Distance 20km

    The RW10 is a high-performance, multifunctional smart terminal device designed for industrial automation, remote monitoring, and field operations. It supports Windows and Ubuntu 20 operating systems, equipped with a 10-inch HD high-brightness display, a 5.8GHz wireless communication module, and a large-capacity battery to meet the demands of various complex applications.

    Key Features

    • Dual-System Support: Supports both Windows and Ubuntu 20 operating systems, catering to different user needs.

    • High-Definition High-Brightness Display: A 10-inch HD high-brightness screen, suitable for outdoor environments with strong sunlight.

    • Long-Range Video Transmission: Equipped with a 5.8GHz wireless communication module, offering video transmission range up to 20KM.

    • Large Capacity Battery: A 4400mAh battery provides long-lasting power for extended use.

  1. Dual-System Support
  2. Sunlight-Readable Display
  3. 20KM Long-Range Wireless
  4. Long Battery Life
